Ultra Flexible Transparent PDMS Film Sheet for Microfluidic Devices Sensors and Flexible Electronics

Short Description:

PDMS (Polydimethylsiloxane) Film Sheet is a high-performance silicone elastomer membrane featuring excellent optical transparency, flexibility, thermal stability, chemical resistance, and biocompatibility. The ultra-soft and elastic structure allows repeated stretching, bending, and deformation while maintaining stable mechanical performance.

PDMS film sheet provide excellent gas permeability, electrical insulation properties, and low surface energy, making them ideal for microfluidic chips, biomedical devices, optical components, flexible sensors, dielectric elastomer actuators, and advanced electronic applications.

Available in customized thicknesses, hardness levels, surface treatments, and die-cut shapes to meet different industrial and research requirements.

Gửi email to us

Product Detail

Product Tags

Ultra Flexible Transparent PDMS Film Sheet for Microfluidic Devices Sensors and Flexible Electronics

Đặc điểm

1. Excellent Optical Transparency

High light transmission and optical clarity make PDMS film suitable for optical observation systems and microfluidic visualization applications.

2. Outstanding Flexibility and Elasticity

Highly stretchable silicone structure enables repeated bending, compression, and deformation without cracking.

3. Wide Temperature Resistance

Maintains stable performance under wide temperature ranges (-40℃~200℃), suitable for demanding industrial environments.

4. Chemical and Weather Resistance

Excellent resistance against moisture, oxidation, UV exposure, and many chemicals.

5. Biocompatible Material

Non-toxic silicone material suitable for biomedical and laboratory applications.

6. Excellent Electrical Insulation

Provides reliable dielectric insulation performance for electronic and sensor applications.

7. Low Surface Energy

Hydrophobic surface characteristics provide excellent release performance and anti-sticking properties.

8. Easy Microfabrication

Compatible with soft lithography, molding, plasma bonding, and microstructure replication processes.

PDMS film sheets are widely used in advanced technology fields requiring soft, transparent, and chemically stable materials. Their unique combination of elasticity, optical clarity, and biocompatibility makes them an excellent choice for precision applications.

Typical applications include:

1. Microfluidic chips and lab-on-chip devices

2. Biomedical diagnostic devices

3. Flexible pressure and strain sensors

4. Optical membranes and lenses

5. Dielectric elastomer actuators

6. Wearable electronic devices

7. Flexible displays

8. Protective coatings and membrane
